Business Introduction
Power cable accessories refer to the intermediate and terminal connections of various cables in a power cable line. Together with the cables, they form the power transmission network. Their main function is to restore the performance of the cable based on its structural characteristics, while also ensuring the extension of the cable length and the proper connection at the terminals.
- Covers a range of cable accessories from medium voltage to high voltage.
- Integrated research and development, production, and sales.
- Integrating Germany's most advanced technology and manufacturing processes with China's strong production and manufacturing capabilities.
- From the Beijing-Tianjin intercity railway to the first aircraft carrier manufacturing base to the first nuclear fusion project.
- Our cable accessories have consistently maintained a leading position in technology and service.
Providing protection for global power transmission.
Related Products
Porcelain-clad oil-filled terminal insulator
Composite insulator type oil-filled terminal
Pre-fabricated intermediate joint with external protective casing
Dry-type plug-in GIS/transformer terminal
Composite insulated dry-type outdoor terminal
Integrated intermediate connector
Three-way intermediate connector
36kV and below T-type connectors
36kV and below extended type connectors
36kV and below cold-shrink indoor terminals
36kV and below cold-shrink outdoor terminals
36kV and below cold-shrinkable intermediate joints
Lightning Arrester
Pluggable internal cone connector (2# sleeve)
Pluggable internal cone connector (Size 3 casing)
Terminal connector
Connector
Grounding Box
JCQ-10 Discharge Counter
115kV polymer-housed surge arrester
FEV-P72.5-245kV Porcelain-clad oil-filled terminal insulator
Porcelain-clad oil-filled cable terminations are suitable for XLPE and EPR insulated cables with aluminum or copper conductors.
- Different models of FEV outdoor terminals are suitable for operating voltages ranging from 72.5 kV to 245 kV.
- The complete terminal assembly includes a porcelain insulator with a metal end plate, a metal base plate with supporting insulators, a pre-molded silicone rubber stress cone with an integrated stress control system, silicone oil for filling the insulator, and a sealed cable connector.
-
Conductor connections can be made using either screw-type or crimp-type methods.
All metal components are made of corrosion-resistant aluminum alloy or stainless steel. - The supplied insulators comply with the IEC 60815 standard under standard pollution levels.
FEV-V 72.5-245kV Composite insulated oil-filled terminal
Oil-filled outdoor cable terminations are suitable for XLPE and EPR insulated cables with aluminum or copper conductors.
- Different models of FEV outdoor terminals are suitable for operating voltages ranging from 72.5 kV to 245 kV.
- The complete terminal assembly includes a composite insulator with a metal end plate, a metal base plate with supporting insulators, a pre-molded silicone rubber stress cone with an integrated stress control system, silicone oil for filling the insulator, and a sealing cable gland.
- Conductor connections are available in both screw-type and crimp-type designs. All metal components are made of corrosion-resistant aluminum alloy or stainless steel.
- The supplied insulators comply with the IEC 60815 standard under standard pollution levels.
SME 72.5-245kV Pre-fabricated intermediate joint with external protective casing
Pre-fabricated intermediate joints with external protective casings, suitable for XLPE and EPR insulated cables with aluminum or copper conductors.
Implementation standards
- IEC 60840
- IEC 62067
KSEV/KTEV 72.5-245kV Dry-type plug-in GIS/transformer terminal
Dry-type plug-in GIS/transformer terminals are suitable for XLPE and EPR insulated cables with aluminum or copper conductors.
- The dry-type KSEV/KTEV terminals are available in different models with design voltages ranging from 72.5 kV to 245 kV.
- The KSEV terminal is suitable for installation in gas-filled cable connection boxes of metal-enclosed gas-insulated switchgear (GIS).
- The KTEV terminal is suitable for installation in oil-filled cable connection boxes of metal-enclosed oil-insulated transformers.
- The complete KSEV/KTEV terminal consists of an epoxy resin insulator with embedded electrodes, a fixing ring, and an insert section. The insert section, which is mounted on the cable, includes a metal cable connector with a spring-loaded clamping device and a silicone rubber stress cone for electric field control. In addition, the terminal is equipped with a corona shield.
- The standard conductor connector is of the screw type. Crimp-type connectors are also available.
- All metal components are made of corrosion-resistant materials.
- We can provide specialized maritime solutions.
TD-V 145kV Composite bushing type dry-type outdoor terminal
Dry-type outdoor terminals, suitable for XLPE and EPR insulated cables with aluminum or copper conductors.
Technical parameters
Voltage (kV) | 145 |
Model | TD145 |
Maximum conductor cross-section (mm²) | 1600 |
Pre-fabricated cable insulation layer diameter (mm) | 34.5-86.0 |
Creepage distance (mm) | ≥4495 |
Length (mm) | 2000±50 |
SME-D 145kV Integrated intermediate connector
Cable connectors allow two different types of cables to be connected to each other.
Pre-fabricated, integrated intermediate joints for XLPE and EPR insulated cables with aluminum or copper conductors.
Implementation standards
- IEC 60840
TJ 145kV Three-part intermediate joint
A cable connector that allows two different types of cables to be connected to each other.
Pre-fabricated three-piece joints for XLPE and EPR insulated cables with aluminum or copper conductors.
Implementation standards
- IEC 60840
CB 17.5-36 T-type connector for 36kV and below
The CB17.5-36 is a shielded T-type separable connector made of silicone rubber, used for connecting cables to ring main units and transformers in power systems up to 36kV (the switchgear and transformers should be equipped with type C1 (630A) bushings that meet EN50180 and EN50181 standards).
- Easy and quick to install.
- Fully shielded and touch-sensitive
- When performing cable sheath testing, it is not necessary to remove the connectors.
- Optional capacitive live measurement points are available.
CC 17.5-36 36kV and below extended type connector
The CC17.5-36 is a shielded, separable connector made of silicone rubber, designed for dual cable connections. It can be connected to the end of a CB product using an M12 double-ended bolt.
- Easy and quick to install.
- Fully shielded and touch-sensitive
- When performing cable sheath testing, it is not necessary to remove the connectors.
- Optional capacitive live measurement points are available.
CSTI 17.5-36 36kV and below cold-shrink indoor termination
CSTI17.5-36 is a fully cold-shrinkable indoor termination made of liquid silicone rubber, used to connect cables to air-insulated switchgear and transformers in power systems up to 36kV. The pre-molded geometric field control unit is unaffected by system frequency and harmonic content.
- Easy and quick to install.
- Pre-expanded end body on the helical support tube
- The outer skirt design is reasonable, providing a long creepage distance.
Implementation standards
- IEC 60502
CSTO 17.5-36 36kV and below cold-shrink outdoor termination
CSTO17.5-36 is a fully cold-shrink outdoor termination made of liquid silicone rubber, used for connecting cables to overhead lines and other outdoor applications in power systems up to 36kV. The pre-molded geometric field control unit is unaffected by system frequency and harmonic content.
- Easy and quick to install.
- Pre-expanded end body on the helical support tube
- The outer skirt design is reasonable, providing a long creepage distance.
Implementation standards
- IEC 60502
CSJS 17.5-36 Cold-shrinkable intermediate joint for 36kV and below
CSJS is a straight-through intermediate connector made of silicone rubber, used for cable connections in power systems up to 36kV.
- Easy and quick to install.
- Pre-expanded end body on the helical support tube
- The support tubes are easy to disassemble and provide reliable installation.
- No special installation tools are required.
- The silicone rubber preform features a one-piece design.
Implementation standards
- IEC 60502
CSA surge arrester
The CSA is a shielded silicone rubber connector housing for metal oxide surge arresters used to protect equipment (such as transformers, switchgear, and cables) in medium-voltage distribution networks. The surge arrester limits overvoltage surges and overvoltage surges caused by voltage wave reflections. The arrester connects directly to the cable connector CB or the extended connector CC, significantly reducing the overall installation depth.
- Easy and quick to install.
- Fully shielded and touch-sensitive
- Optional capacitive live measurement points are available.
Implementation standards
- IEC 60099-4
CPI-2 Pluggable internal cone connector (size 2 casing)
The CPI-2 is a shielded inner cone connector made of silicone rubber, used for connecting switchgear or transformers in 52kV power systems. The switchgear and transformers should be equipped with bushings that meet EN50180/50181 standards (size 2).
- Easy and quick to install.
- Fully shielded and touch-sensitive
- Multi-segment conductor connector with contact pads
- Equipped with an internal stress control system.
Implementation standards
- IEC 60502
- EN 50181
- EN 50180
CPI-3 Pluggable internal cone connector (size 3 casing)
The CPI-3 is a shielded inner cone connector made of silicone rubber, used to connect switchgear or transformers in 52kV power systems. The switchgear and transformers should be equipped with a size 3 interface that meets EN50180/50181 standards casing.
- Easy and quick to install.
- Fully shielded and touch-sensitive
- Multi-segment conductor connector with contact pads
- Equipped with an internal stress control system.
Implementation standards
- IEC 60502
- EN 50181
- EN 50180
Wire clips Terminal connectors
Technical parameters
Model and specifications | DN40-50 |
Length/mm | 164 |
Height/mm | 94 |
Width/mm | 86 |
Cable cross-sectional area/mm² | 240~2500 |
Internal hexagon bolt connector Connector (joint)
The internal hexagon bolt connector is primarily used in SME145 connectors for high-voltage cable accessories. Its main function is to connect the two ends of the cable conductor, restoring reliable mechanical and electrical connection performance.
Implementation standards
- IEC 60840
Grounding box for 72.5-245kV cable systems Grounding box
Grounding boxes are installed at cable terminals and joints, connected to the cable's metal sheath, and are used to limit overvoltages and fault currents in the cable's metal sheath caused by lightning strikes and operational conditions. Cross-bonding grounding boxes are installed at joint locations to cross-bond the cable's metal sheaths, suppressing surge voltages and reducing circulating currents. The shielding voltage limiter (SVL) in the link box is a gapless zinc oxide arrester with an insulation resistance greater than 200 MΩ at the test voltage, so the SVL connection can function normally during cable sheath insulation testing. The specifications of the SVL can be determined according to the requirements of the cable system.
- Different models of grounding boxes are suitable for cable systems ranging from 72.5 kV to 245 kV.
- The types of connection boxes include direct connection boxes (without SVL), protected connection boxes (with SVL), and cross-interconnection grounding boxes.
- Grounding boxes are designed according to different customer requirements, including 3-way type 1 or 6-way type 1 configurations, single-core or coaxial cable application types, and various waterproof designs.
Implementation standards
- IEC 60840
- IEC 62067
- GB/T 2630-2023
Discharge Counter and Detector JCQ-10 Discharge Counter
The JCQ-10 discharge counter is connected in series below the surge arrester and is used to record the operating time of the surge arrester. The JCQ-10 is suitable for surge arresters with voltage ratings from 6kV to 245kV.
Implementation standards
- IEC 60099-4
115kV polymer-housed surge arrester
Surge arresters help prevent lightning damage to equipment caused by high voltage. They provide a low-impedance path for lightning currents to flow directly to the ground, and then return to their normal operating state.
Implementation standards
- IEC 60099-4
